NHP DTRT0630A DIN-T Residual Current Breaker RCBO 10kA 3 Pole and Neutral 6A C Curve 30mA Type A (Longbody)
Code: NHPDTRT0630A
Unit of measure:
EACH
Description
NHP DTRT0630A DIN-T Residual Current Breaker RCBO 10kA 3 Pole and Neutral 6A C Curve 30mA Type A (Longbody)
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Rated residual make/break capacity | 6000A |
| Electrical life at Un- In (service cycles) | 10000 |
| Voltage type | AC |
| Leakage current type | A |
| Depth | 77.1mm |
| Connectable conductor cross section multi-wired | 1-16mm2 |
| Rated current | 6A |
| Rated impulse withstand voltage Uimp | 4kV |
| Rated short-circuit breaking capacity according to EN 61009 | 10kA |
| Rated voltage | 415V |
| Width in number of modular spacings | 3 |
| Min. service voltage | 207V |
| Height | 117.5mm |
| Concurrently switching neutral conductor | 0 |
| Width | 54mm |
| Connectable conductor cross section solid-core | 1-25mm2 |
| Rated insulation voltage Ui | 500V |
| Mechanical life (service cycles) | 20000 |
| Type of electric connection | Fork and pin |
| Tripping time | 300ms |
| Pole Configuration | 4 Pole |
| Max. operating voltage (Umax) | 457V |
| Weight | 0.55mm |
| Brand Name | NHP |
| IP Rating | IP40 |
| Mounting method | DIN rail |
| Disconnection characteristic | Undelayed |
| Frequency | 50/60 Hz |
| Operating temperature | -5-55 Degree |
| Rated leakage current | 30mA |
