Schneider Electric C103MA003 Trip unit MA2.5, ComPacT NSX100, 3 poles, magnetic protections, motor protection, 2.5A rating
Code: SCHC103MA003
Unit of measure:
EACH
Description
TRIP UNIT NSX100 AC 3P3D 2.5A MA
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| [In] rated current | 2.5 A at 65 °C |
| Ambient air temperature for operation | -25-70 °C |
| Instantaneous pick-up adjustment type Ii | adjustable 9 settings |
| Earth-leakage protection | without |
| Mounting mode | fixed |
| Supplier Code | C103MA003 |
| Instantaneous pick-up adjustment range | 6...14 x In |
| Ambient air temperature for storage | -50-85 °C |
| Poles description | 3P |
| Trip unit name | MA |
| Network frequency | 50/60 Hz |
| Trip unit protection functions | I |
| Protected poles description | 3D |
| Protection type | I : for short-circuit protection (magnetic) |
| Network type | AC |
| Trip unit technology | magnetic |
| Device application | motor |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Range | ComPacT new generation |
| Standards | EN/IEC 60947-2 |
| Brand Name | Schneider Electric |
| Electrical shock protection class | class II |
| Range compatibility | ComPacT new generation NSX100 |
| Pollution degree | 3 conforming to IEC 60947-1 |
| Product or component type | trip unit |
