Schneider Electric GV4LE25N TeSys GV4 Motor Breaker Gv4Le Mag 25A 50Ka Elink

Code: SCHGV4LE25N

Brand: Schneider Electric

Unit of measure: EACH

Description

Schneider Electric GV4LE25N TeSys GV4 Motor Breaker Gv4Le Mag 25A 50Ka Elink

TeSys GV motor circuit breaker, 3 poles (3P), 25A/690V, for protection of 3-phase motors 5.5-11kW@400V. It provides magnetic protection, breaking capacity Icu 50kA@400V, start-stop control by toggle, connection by Everlink BTR screw terminals. Magnetic protection adjustable by dial, setting range 6-14 In. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). To be used in association with a class 10 or 20 thermal overload relay to complete motor protection. Multi standards certified (IEC, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Operating position	any position
Suitability for isolation	yes conforming to IEC 60947-1
[In] rated current	25 A
Ambient air temperature for operation	-25-70 °C
Depth	116 mm
Colour	Grey
Fire resistance	960 °C conforming to IEC 60695-2-11
[Ith] conventional free air thermal current	115 A conforming to IEC 60947-4-1
Supplier Code	GV4LE25N
Climatic withstand	conforming to IACS E10
Mechanical durability	40000 cycles
Ambient air temperature for storage	-50-85 °C
Direct connector	without
Height	155mm
Poles description	3P
Width	81mm
YoutubeVideo1	https://www.youtube.com/embed/gj6wLOSXVLk?si=8QxgtV7sB9XQPTQz
Operating altitude	5000 m
360Image	https://visuals.se.com/GV4LE25N_360VH_ODA20/20201223T1435/360
Device short name	GV4L
Device application	motor protection
[Ue] rated operational voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
Control type	toggle
Magnetic tripping current	150-350 A
[Ui] rated insulation voltage	800 V AC 50/60 Hz conforming to IEC 60947-2
Range	TeSys Deca
maximum operating rate	25 cyc/h
Brand Name	Schneider Electric
[Uimp] rated impulse withstand voltage	8 kV conforming to IEC 60947-2
Power dissipation per pole	6.1 W
IP Rating	IP40 conforming to IEC 60529
Product name	TeSys GV4
Pollution degree	3
Net weight	1.5 kg
Rated duty	continuous conforming to IEC 60947-4-1
IK degree of protection	IK07 conforming to IEC 62262
Product or component type	motor circuit breaker
