Schneider Electric LA1KN04 Auxiliary contact block, TeSys K, 4NC, front mounting, screw clamp terminals
Code: SCHLA1KN04
Unit of measure:
EACH
Description
ADD ON BLOCK 4NC
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Associated fuse rating | 10 A gG at <= 690 V conforming to IEC 60947 |
| Permissible short-time rating | 60 A 500 ms |
| Depth | 35mm |
| Ambient air temperature for operation | -25-50 °C |
| Minimum switching current | 5 mA |
| Pole contact composition | 4 NC |
| Non overlap distance | 0.5mm |
| Auxiliary contacts operation | instantaneous |
| Irms rated making capacity | 110 A at <= 690 V AC conforming to IEC 60947 |
| [Ith] conventional free air thermal current | 10 A (at 50 °C) |
| Supplier Code | LA1KN04 |
| Environmental characteristic | normal environment |
| Ambient air temperature for storage | -50-80 °C |
| Minimum switching voltage | 17 V |
| Height | 30mm |
| Width | 38mm |
| Operating altitude | 2000 m |
| Device short name | LA1 |
| Shielding continuity terminal | without |
| Compatibility code | LA1 |
| [Ue] rated operational voltage | 690 V AC 25...400 Hz |
| Insulation resistance | > 10 MOhm |
| IP degree of protection | IP20 conforming to IEC 60529 |
| [Ui] rated insulation voltage | 600 V conforming to CSA C22.2 No 60947-5-1 |
| Range | TeSys |
| Standards | GB/T 14048.5 |
| Brand Name | Schneider Electric |
| Product certifications | CE |
| Range compatibility | TeSys K CA3K |
| Product name | TeSys K |
| Protective treatment | TC conforming to IEC 60068 |
| Tightening torque | 1.3 N.m - with screwdriver pozidriv No 2 |
| Mounting location | front |
| Net weight | 0.045 kg |
| Product or component type | auxiliary contact block |
| Connections - terminals | screw clamp terminals 2 cable(s) 0.75-4mm²flexible without cable end |
