Allen-Bradley 700HK32Z244 700-HK General Purpose Slim Line Relay 8A 2 CO DPDT 24V DC Coil with Pilot Light
Code: A-B700HK32Z244
Unit of measure:
EACH
Description
Allen-Bradley 700HK32Z244 700-HK General Purpose Slim Line Relay 8A 2 CO DPDT 24V DC Coil with Pilot Light
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Max. shock acceleration | 50g |
| Nominal current | 8:00:00AM |
| Max. vibration frequency - operational | 2000Hz |
| Rated switching power at AC-1 | 2000VA |
| Mechanical life (service cycles) | 10000000 cycles |
| Max. vibration acceleration | 5m/s² |
| Type of electric connection | Plug-in connection |
| Number of contacts as change-over contact | 2 |
| Voltage type for actuating | DC |
| Electrical life at Un - In (service cycles) | 30000 cycles |
| Material contact | Silver nickel |
| Depth | 32.8mm |
| Nominal voltage AC | 250V |
| Brand Name | Allen-Bradley |
| With LED indication | Yes |
| Rated switching power at AC-15 - 230V | 350 VA |
| IP Rating | IP20 |
| Control supply voltage Us at DC | 24V |
| Supplier Code | 700HK32Z244 |
| ETIM Class | Switching relay |
| Height | 29mm |
| Suitable for plug-in socket mounting | Yes |
| Width | 12.4mm |
| Operating temperature | -40-70°C |
