NHP CS822Z110VAC S+S CS8 Relay 110VAC Coil 2NO 2NC Contact
Code: NHPCS822Z110VAC
Unit of measure:
EACH
Description
NHP CS822Z110VAC S+S CS8 Relay 110VAC Coil 2NO 2NC Contact
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Control supply voltage Us at AC 60HZ | 110V |
| Nominal current | 6A |
| Coil Current Type | AC |
| Type of electric connection | Screw connection |
| Mount | Din Rail |
| Voltage type for actuating | AC |
| Number of contacts as normally closed contact | 2 |
| Range | C8 Series |
| Frequency Rating | 50/60 Hz |
| Brand Name | NHP |
| Item Name | Control Relay |
| EAN/UPC | 2000000691725 |
| Type | Industrial |
| Current Type | AC/DC |
| Contact Configuration | 2 NO + 2 NC |
| IP Rating | IP20 |
| Voltage | 600 V |
| Number of contacts as normally open contact | 2 |
| Supplier Code | CS822Z110VAC |
| Coil Voltage | 110 V |
| ETIM Class | Switching relay |
| Current | 10A |
| Control supply voltage Us at AC 50HZ | 110V |
